产品详情

Specifications:

Standard XY Stage travels (other travels available as "non-standard" orders)	4"x4", 8"x8", 12"x12" and 18"x18"
Number of motorized axes	3 axes (i.e. XYZ) standard (up to 20 axis of motion available in "non-standard" configurations)
XY encoder resolution	0.1 um
Standard Z axis travel (other travels available as "non-standard" orders)	6"
Z encoder resolution	0.1 um
Stage movement	High-accuracy crossed roller movement
Motion parameters (i.e. speed, convergence criteria, etc...)	User-selectable
Camera	High-resolution color digital camera (progressive scan)
Illumination	Programmable, computer-controlled
Optics	High-power, long working distance
Power zoom	Available as an option
External joystick	Yes (3-speed, 3-axis)
On-screen joystick	Yes (3-speed, 3-axis)
Software	VisionGauge Online
Software interface	Graphical (i.e. "point & click")
Built-in SPC software with automatic numerical charts & Pass / Fail graphs	Yes
Automatic data export to Excel™	Yes
Automatic data export to other applications	Yes (through Windows™ DDE or other mechanisms)
Built-in Dynamic Data Exchange (DDE) support	Yes
Easy file data import & export	Yes
Programming	All done with mouse & joystick, through the software's Graphical User Interface, and through the software's "teach" mode
Pattern macthing tools	Yes
Optical Character Recognition & Verification (OCR / OCV) tools	Yes
OCR / OCV character library	No limitations (i.e. the system is "trainable")
Color verification tools	Yes
Measurement tools	Wide range of edge-detection based sub-pixel accurate 3D measurement tools
Image analysis tools	Yes
Image manipulation & image processing tools	Yes
Counting & Sizing (i.e. "blob analysis") tools	Yes
Automatic registration tools (i.e. to correct for variations of both translation & rotation)	Yes
Auto-Focus	Very robust and accurate, with user-selectable region-of-interest and search range
Non-destructive live image overlays	Yes (user-selectable)
Auto-Scan tool (for automatic defect detection on large samples)	Yes
Ability to automatically save image of defects	Yes
Post-analysis Pass / Fail summary report (to allow the operator review & override results)	Yes
Built-in ability to interface to other (external) equipment & machinery	Yes
Built-in password supervisor-level / operator-level protection	Yes
Calibration	NIST-traceable
Built-in "F1 Help"	Included
Clear and easy-to-use documentation (both printed and "pdf" format)	Included
Support (by phone, fax & email)	Included for a full year
Warranty	1 year (complete)
